Socktop WebTerm

A web-based terminal using xterm.js and Rust, part of the Socktop project.

This is the repository and CICD for socktop.io

About

This is a modern web terminal server that provides browser-based terminal access with WebSocket support. It's built with Rust using the Actix-Web framework and xterm.js for the frontend.

Features

• Full-featured terminal emulation via xterm.js
• WebSocket-based communication using the Terminado protocol
• High-performance Rust backend
• Privacy-focused analytics with Umami (self-hosted)
• Command sanitization for security and privacy
• Zero-downtime rolling deployments via CI/CD
• Containerized deployment with Docker
• Kubernetes/k3s ready with automated deployments

Architecture

The application consists of two main components:

Backend (Rust)

• Websocket Actor: Implements WebSocket communication using the Terminado protocol
• Terminal Actor: Manages PTY communication with spawned processes using portable-pty
• Actix-Web Server: Serves static files and handles HTTP/WebSocket routing

Frontend

• xterm.js: Provides the terminal UI in the browser
• Static Assets: HTML, CSS, and JavaScript served by Actix-Web

Prerequisites

• Rust 1.90+ (2021 edition)
• Node.js and npm (for xterm.js dependencies)
• Docker (optional, for containerized deployment)
• Kubernetes/k3s (optional, for orchestrated deployment)

Local Development

# Clone the repository
git clone https://gt.wittyoneoff.com/jason/socktop-webterm
cd socktop-webterm

# Install npm dependencies
npm install

# Verify setup (optional but recommended)
./check-setup.sh

# Build and run
cargo build
cargo run

Then head to http://localhost:8082/ to see it in action!

Setup Verification

Before running the server, you can verify that all required files and dependencies are in place:

./check-setup.sh

This will check for:

• Required directories (static, templates, node_modules)
• Critical files (templates, JavaScript, CSS)
• xterm.js installation
• Build tools (cargo, npm)

Note: The server must be run from the project root directory, as it expects ./static, ./templates, and ./node_modules to be accessible in the current working directory.

Command Line Options

webterm-server --help

Options:

• -p, --port <PORT> - The port to listen on (default: 8082)
• -H, --host <HOST> - The host or IP to listen on (default: localhost)
• -c, --command <COMMAND> - The command to execute (default: /bin/sh)

Example:

cargo run -- --port 8080 --host 0.0.0.0 --command /bin/bash

Production Deployment

Docker

# Build the image
docker build -t socktop-webterm:latest .

# Run the container
docker run -d -p 8082:8082 socktop-webterm:latest

Kubernetes/k3s

Automated deployment via Gitea Actions CI/CD:

1. Push to main branch
2. Workflow automatically builds arm64 image
3. Image tagged with version from Cargo.toml
4. Deployed to k3s cluster with zero-downtime rolling update

See .gitea/workflows/build-and-deploy.yaml for the complete workflow.

Manual deployment:

kubectl apply -f kubernetes/

CI/CD Pipeline

This project includes a complete CI/CD pipeline using Gitea Actions:

• Automatic builds on every push to main
• Version tagging from Cargo.toml
• Container registry integration
• Automated k3s deployment with rolling updates
• Zero downtime deployments

Technology Stack

• Backend: Rust 2021, Actix-Web 4.x, Actix 0.13, portable-pty
• Frontend: xterm.js, HTML5, CSS3
• Templating: Handlebars 6.x
• CLI: clap 4.x
• Async Runtime: Tokio 1.x
• Containerization: Docker, Kubernetes/k3s
• CI/CD: Gitea Actions

Security and Limitations

Security Model

This application is designed to provide safe, public terminal access for demonstration purposes. The security model consists of multiple layers:

1. Restricted Shell

When deployed in production (e.g., https://www.socktop.io), the application uses a restricted shell (docker/restricted-shell.sh) that:

• Allows only 2 commands: socktop and help
• Blocks all other commands: Rejects any attempt to run ls, cat, bash, etc.
• Validates arguments: All arguments passed to socktop are sanitized to prevent command injection
• Prevents shell escapes: Blocks metacharacters like ;, &&, |, $(), backticks, etc.
• Blocks path traversal: Prevents attempts like ../../../etc/passwd

Example validation:

# Allowed
socktop -P local
socktop -P rpi-master
socktop ws://192.168.1.100:3000

# Blocked with error message
socktop $(whoami)          # Command substitution blocked
socktop ; /bin/bash        # Shell metacharacter blocked
socktop -P ../etc/passwd   # Path traversal blocked

2. Argument Sanitization

The restricted shell validates all input using regex patterns:

• Profile names: Only [a-zA-Z0-9_-]+ characters allowed
• WebSocket URLs: Only ws:// or wss:// with safe characters
• No environment variable expansion
• No special characters or shell operators

Security testing: Run ./scripts/test-shell-security.sh to verify all 35 security checks pass.

3. Container Isolation

• Runs inside Docker container (cannot access host system)
• Non-root user (socktop user)
• Limited resources (CPU/memory limits configurable)
• No privileged operations
• Read-only configuration mounts

4. WebSocket Security

The WebSocket endpoint (/websocket) is secure by design:

• Command spawned is hardcoded at server startup (via --command flag)
• No way to change which shell is spawned via WebSocket connection
• No HTTP headers or request parameters influence the spawned command
• Direct WebSocket connections get the same restricted shell as browser connections

The Terminado protocol only supports:

• stdin - Send input to terminal (goes through restricted shell)
• stdout - Receive output from terminal
• set_size - Resize terminal (validated to u16 row/col numbers only)

There is no protocol message type that can bypass the shell or execute arbitrary commands.

Reporting Security Issues

If you discover a security vulnerability that bypasses the restricted shell or container isolation, please report it via:

• GetTea Issues (for non-critical issues)
• Direct contact to maintainer (for critical vulnerabilities)

Credits

This project was originally forked from webterm by Fabian Freyer. I chose this as a base because other projects were way too complex. His project was simple and easy to understand, but it was not well maintained. I have updated it to modern packages and heavily customized it to display a working demo for socktop.

Original Author

This project is a fork of webterm originally created by:

• Fabian Freyer (fabian.freyer@physik.tu-berlin.de)

Socktop Enhancements

Modernized and enhanced for the Socktop project by:

• Jason Witty (jasonpwitty+socktop@proton.me)

Major Changes from Original

• Updated to Rust 2021 edition
• Modernized dependencies (Actix-Web 1.x → 4.x, Tokio 0.1 → 1.x)
• Replaced deprecated tokio-pty-process with portable-pty
• Added automated CI/CD pipeline with Gitea Actions
• Containerized deployment with Docker
• Kubernetes/k3s orchestration support
• Added idle session timeout (5 minutes)
• Improved error handling and logging
• Modern CLI with clap instead of structopt
• Updated to latest xterm.js

License

This project is licensed under the BSD 3-Clause License - see below:

Copyright (c) 2019 Fabian Freyer
Copyright (c) 2024 Jason Witty
All rights reserved.

Redistribution and use in source and binary forms, with or without
modification, are permitted provided that the following conditions are met:

1. Redistributions of source code must retain the above copyright notice,
   this list of conditions and the following disclaimer.

2. Redistributions in binary form must reproduce the above copyright notice,
   this list of conditions and the following disclaimer in the documentation
   and/or other materials provided with the distribution.

3. Neither the name of the copyright holder nor the names of its contributors
   may be used to endorse or promote products derived from this software
   without specific prior written permission.

THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS "AS IS"
AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE
ARE DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT HOLDER OR CONTRIBUTORS BE
LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR
CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF
SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS
INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN
CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE)
ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE
POSSIBILITY OF SUCH DAMAGE.

Contributing

Contributions are welcome! Please feel free to submit pull requests or open issues.

Links

• Repository: https://gt.wittyoneoff.com/jason/socktop-webterm
• Original Project: https://github.com/fubarnetes/webterm
• xterm.js: https://xtermjs.org/
• Actix-Web: https://actix.rs
• portable-pty: https://crates.io/crates/portable-pty
